Plug in galvanized grating
Surface Treatment: Hot Dip Galvanized
Shipping Method: Logistics
Product Category: Steel Grating, Press-Locked Grating
Appearance: Plug-in type, interlocked structure, flat or serrated surface, silver finish
Price: $18.00-$45.00/m², the price of plug in galvanized grating is not fixed and is influenced by size, thickness, bar spacing and order quantity. For more details, please consult us.
Performance
The properties of plug in galvanized grating are as follows:
Strong Mechanical Lock: Pressure-locked joints provide secure connections without weld points, maintaining structural integrity under load.
Excellent Corrosion Protection: Hot dip galvanized coating provides long-term rust resistance in outdoor and industrial environments.
Smooth Appearance: No welding marks on surface, cleaner and more aesthetically pleasing than welded grating.
High Strength-to-Weight Ratio: Rigid structure with relatively light weight for easy handling and installation.
Good Slip Resistance: Serrated surface option available for enhanced safety in wet conditions.
Low Maintenance: Galvanized finish eliminates need for painting or regular upkeep.
Customizable Patterns: Flexible bar spacing and sizes to meet specific load and design requirements.
Application
Plug in galvanized grating is primarily used in the following engineering fields:
Architectural Applications: Decorative grilles, sunshades, facade elements, ceiling panels where appearance matters.
Industrial Walkways: Light to medium duty platforms, catwalks, and access paths in factories and warehouses.
Public Facilities: Pedestrian bridges, park walkways, stadium seating vents, and tree grates.
Transportation: Airport flooring, subway ventilation grilles, and railway platform edges.
Commercial Buildings: Stair treads, entrance mats, mezzanine floors, and ventilation covers.
Food Processing: Flooring and platforms where smooth surfaces are easier to clean than welded grating.
Municipal Projects: Drainage covers, trench grates, and public space applications requiring both strength and appearance.
Specifications
The following table outlines typical specifications for plug in galvanized grating.
| Property | Unit | Typical Value / Range | Test Method |
|---|---|---|---|
| Material | — | Q235 Mild Steel | GB/T 700 |
| Flat Bar Size | mm | 15×2, 20×3, 25×3, 30×3, 32×5, 40×5, 50×5 | Customized |
| Cross Bar Size | mm | 5×5, 6×6, 8×8 square or round | — |
| Surface Type | — | Plain (Flat), Serrated (Toothed) | — |
| Surface Treatment | — | Hot Dip Galvanized (HDG) | GB/T 13912 |
| Zinc Coating Thickness | μm | ≥ 80 (average) | GB/T 13912, ISO 1461 |
| Center Distance | mm | 20×20, 30×30, 40×40, 50×50, 30×100 | Customized |
| Bearing Capacity | kN/m² | ≥ 20–150 (depending on design) | GB/T 13912 |
| Joint Strength | — | Firm lock, no loosening | — |
